User Hub

The User Hub consists of a collage of existing content displayed on the home page of the main client interface for Pyramid.

The user hub is defined by the Admin, but each user can edit their own view of the user hub.

Access the User Hub

To open the hub, go to the My Hub tab (blue highlight below) in the Content Manager.

Navigate the User Hub

  • Tabs: click the relevant tab to open it (orange highlight below).
  • Reset All:reset all items in the hub to their most recently saved state (yellow arrow below).
  • Rerun Queries: run all queries in the hub (green arrow below).
  • Edit: edit the hub template (purple arrow below).

Content Types

The user hub can display the following types of content:

  • Widget Presets: a selection of pre-designed widgets featuring various views from the Content Manager.
  • Discoveries and Presentations: data discoveries and presentations can be added directly to the hub within their own containers.

In the image below, the 2 green arrows indicate data discoveries; the red arrow indicates a presentation, and the yellow arrow indicates a widget preset.

Edit the User Hub

Click the Edit icon to open the User Hub in edit mode. Once in edit mode, you can resize and reposition the widgets and containers as needed. A number of functions for editing will be exposed.

Macro Functions

The macro functions (yellow highlight below) for editing are found along the top of the hub editor.

  • Add Tab: add a new tab to the hub.
  • Delete Tab: click a tab's "x" to delete it.
  • Rename Tab: tabs are automatically named "Tab 1", "Tab 2", etc. Click the tab header to rename it (purple highlight above).
  • Add Content or Widget: find and select content or widgets to add to the current tab.
  • Reset: discard changes and revert to the default user hub.
  • Tab Manager: open the Tab Manager to see a list of current tabs.
  • Save: save changes to all tabs and exit edit mode.
  • Cancel: discard all changes and exit edit mode.

Tab Manager

Open the Tab Manager to see a list of current tabs. The list displays any new tabs added by to the template by the Admin. Click the corresponding icon (yellow highlight below) to add the new tab to your hub.

Container Functions

Drag, drop, and resize (yellow arrow below) the containers as needed from edit mode. The following functions are found at the top right of the widget and content containers.

  • Optimize Size: (only for presentations) optimize the container size to the presentation size (green arrow below).
  • Switch To: swap the widget out for a different item (red arrow below).
  • Remove: remove the widget from the tab (purple arrow below).

Add Content or Widget

You can add widget presets, data discoveries, and presentations to the hub. The "Add Content or Widget" button appears in the macro functions (yellow arrow below), and as a tile on new tabs (purple highlight below). This opens a content directory (yellow highlight below) that exposes several content manager views and widget presets; click on the relevant item to add it to the current tab.
